Abatement Technologies HEPA-CARE® UV800F Module
in stock
UV800F Germicidal UV Disinfection Module
Enhanced UV-C protection for HEPA-filtered clean air exhaust systems.
The UV800F is an easy-to-install UV disinfection module designed to integrate directly with the HC800FD Ceiling-Mounted HEPA Filtration System. It adds an extra layer of airborne pathogen control by irradiating clean, HEPA-filtered air before it's exhausted or recirculated. Ideal for use in hospitals and healthcare environments, the UV800F is engineered for continuous air cleaning and added infection control during both routine care and emergency response.
Quick & Simple Installation
The UV800F mounts directly to the clean air exhaust grille of the HC800FD unit. Slide the module into the offset tabs, secure it with the provided fasteners, and plug the included short power cord into the built-in GFCI outlet on the HC800FD — no additional wiring or wall outlets required. Once installed, the UV800F typically stays in place for long-term use.
Built-In Performance Features
-
High-Output UV-C Lamp
Provides strong germicidal irradiation for maximum air disinfection. -
Long Lamp Life
Designed for extended service intervals to reduce maintenance. -
Easy Lamp Replacement
Simplifies routine servicing without removing the unit.
Integrated Safety Features
-
Complete Lamp Shielding
Prevents direct UV-C exposure to users and patients. -
Automatic Safety Interlocks
Instantly shut off UV-C lamps if the airflow is interrupted or the lamp compartment is opened. -
Independent On/Off Switch
Enables manual control when needed. -
NRTL-Certified
Conforms to applicable UL and CDC safety standards for healthcare use.
Ideal Applications in Healthcare Settings
-
Airborne Infectious Isolation Rooms
Irradiate HEPA-filtered exhaust air and disinfect recirculated air between patients. -
Protective Environments & Operating Rooms
Enhance protection for immunocompromised and post-op patients. -
General Room Air Disinfection
Improve air quality in waiting rooms, bronchoscopy suites, pediatrics, outpatient clinics, autopsy rooms, and more. -
Bioterrorism & Outbreak Response
Deploy as part of negative pressure isolation zones during infectious emergencies.
The UV800F is a smart, safe upgrade that strengthens infection control in any space using HEPA filtration — with simple installation and long-term reliability.
| Dimensions (L x W x H) |
Footprint 2'6' x 5'0 (30” x 60”)
|
| Maximum Accessible Ceiling Height |
With Mobile Cart: 10'0 Without Mobile Cart: 9'3
|
| Net Weight |
Including Mobile Cart: 93 lb Excluding Mobile Cart: 71 lb
|
| Casters |
5” x 1” Heavy-Duty, with Bearings (2 Fixed, 2 Swivel)
|
| Frame Material |
0.100 Corrosion-Resistant Aluminum
|
| Cart Construction |
Solid-Rivet, Aircraft Construction
|
| Upright Poles |
0.120 Aluminum
|
| Top Frame Material |
0.100 Corrosion-Resistant Aluminum
|
| Large Clear Viewing Windows |
Yes, 4 Total (1 Per Side)
|
| Transparent Information Pocket |
Yes
|
| FR Specifications |
Federal Std. 191A, Test Method 5903, MVSS 320, CA Fire Marshall
|
| Portable Air Scrubber Attachment Port |
Yes, Fits 8, 10 & 12 Inlet Collars
|
| Passthrough Ventilation Port |
Yes
|
| Door Opening |
Zippered Entry / Exit Door
|
| Approvals |
Meets JCAHO EC.5.50.2 for Smoke-Tight Enclosures. Meets Relevant CDC, CSA Z317 13-03, AIA, ASHE & NFPA 701 Life Safety Code Requirements.
|
| Port Size |
HEPA Vacuum Port: Yes, Fits up to 3 Hose
|
| Cart Load Rating |
900 lb
|
| Minimum Height When Lowered |
Minimum Usable Ceiling Height ( on Cart): 7'0 Minimum Usable Ceiling Height (off Cart): 6'3
|
